The Yeoman CL8HB Multifuel and Woodburning Boiler Stove
The CL8 boiler stove is based on the standard CL8 wood burning stove, but will also supply you with hot water and central heating.
Complete home heating with cutting edge style (Click on images to enlarge)
All Yeoman boiler stoves can be used in their own right to heat domestic hot water and provide central heating – they will also augment an existing central heating system with ‘link up’ technology
The CL8 boiler stove will feed up to 9 standard size radiators (A standard size radiator is considered to be 400 x 1000mm)
The contemporary CL8HB burns anthracite, smokeless fuels and peat turfs with the use of a Multi-fuel kit (choice of static or riddling grate versions)
The Cl8HB provides up to 34,000 BTU, enough to supply 9 average radiators and a further 8,000 BTU to feed an average hotwater cylinder
Yeoman Airwash System - to give a clearer view of the stove's flames
5mm and 10mm heavy duty steel body
4 x 1" BSP boiler tappings for flexible efficient connection to your hot water circuits
Extensive water jacket on 4 sides of the stove to ensure maximum transmission of heat to water
Highly developed boiler flue baffle system to ensure maximum heating efficiency
Top or Rear Flue - 153mm (6")
Primary air controls to manually adjust the running temperatures
Optional thermostatic control to maintain desired running temperatures
Optional woodburning tray
As with all Yeoman high-output boiler stoves, the CL8HB boiler stove is designed for multi fuel use and incorporates an externally operated riddling grate.
Solid mineral fuels tend to provide greater calorifc values, should you wish to reduce your CO2 emissions then you can also burn a combination of smokeless fuels and logs together.
If woodburning only is your preference, you can still achieve good performance but, as logs burn best with slightly different firebox characteristics, we recommend you purchase the optional log tray which replaces the riddling system
This stove is supplied with a FREE Installation Kit and Fire Starter Kit, saving you up to £100
Call us now on 0113 2555622 for more information
Heat Output : 13kW (4.9kW to room, 8.2kW to boiler)
Efficiency :N/A
Flue Size : 6" (153mm)
Fuel Type : Multifuel and wood
Flue Options : Top or Rear (Interchangeable)
Approx Weight : 150 kgs
Warranty : 5 Years for Castings & 2 Years for Steel Carcass (subject to the stove being serviced 12 months after installation)
Radiators capability: 9 (Guide only)
